No. |
Item |
Unit |
5XF-100 |
|
1 |
Travel tyle |
/ |
Trailed |
|
2 |
Overall dimension (length×width×height) |
mm |
15000x3200x3100 |
|
3 |
Machine weight |
kg |
7780 |
|
4 |
Maximum processing capacity |
t/h |
100 |
|
5 |
Conveyor belt drive type |
/ |
Hydraulic motor |
|
6 |
Power mode |
/ |
Motor drives gear pump |
|
7 |
Motor power |
Kw |
18 |
|
8 |
Oil tank volume |
L |
90 |
|
9 |
Power supply requirements |
/ |
AC380V, 50HZ |
|
10 |
Control type |
/ |
触控 + 按钮 Touch + button |
|
11 |
Receiving conveyor belt width |
mm |
720 |
|
12 |
Lifting/pitch of the manual picking up web |
mm |
45 |
|
13 |
Lifting/width of the manual picking up web |
mm |
1550 |
|
14 |
Cleaning structure |
/ |
Polyurethane spiral roller/spring cleaning roller |
|
15 |
Cleaning roller gap adjustment range |
mm |
0-45 |
|
16 |
Manual picking position |
个 |
6-8 |
|
17 |
Receiving arm length |
mm |
4400 |
