No. |
Item |
Unit |
4UL-170D |
4UL-170E |
|
1 |
Structural style |
/ |
Trailed |
|
|
2 |
Overall dimension (length×width×height) |
mm |
9210×3400×3000 |
9627×3147×3031 |
|
3 |
Machine weight |
kg |
6500 |
5500 |
|
4 |
Supporting power |
hp |
140-210 |
140-210 |
|
5 |
Working width |
mm |
1700 |
1800 |
|
6 |
Type of depth limiting mechanism(depth limiting wheel, others) |
/ |
Depth limiting wheel |
Depth limiting wheel |
|
7 |
Excavation depth adjustment range |
mm |
150-300 |
150-300 |
|
8 |
Type of device for removing haulm and weeds |
mm |
Counter-rotating rollers for removing haulm |
Screen type to remove haulm |
|
9 |
Type of digging device |
/ |
Fixed combined shovel |
Fixed combined shovel |
|
10 |
Type of cleaning and separation device (vibrating screen, others) |
/ |
Conveying chain grid screen+Star rubber wheel |
vibrating screen |
|
11 |
Type of conveying device (grating chain type, belt type, others) |
/ |
Grid chain |
Grid chain |
|
12 |
Work efficiency |
ha/h |
≥ 0.4 |
≥ 0.33 |
